MODEL K, G
MODEL K, G
MODEL K, G
- Used in areas threatened by corrosion
- for particularly quiet running, which doesn’t damage the ground
- at lower demand on carrying capacity and robustness than the steel wheel
- In cases of minimal electic conductivity (plastic)
- For transporting loads at a maxium speed of 100m/min
Characteristics
- Solid basic construction with ball bearings
- Delivered with various mountings
- Special construction to suit customer requirements .
- Passed the DIN 4422 test at the material research laboratory for plastic wheel 150k
Hints on use
- Construction free of maintenance with advanteges over the steel wheel particularly in maritime environments or where is danger of corrosion
- can be combined with fixed castors and swivel castors
- Material doesn’t damage the ground, but is more susceptible than steel when handled roughly
| Size | a | b | Ø d1 | Ø d2 | Ø d3 | suitable suspensions of the series |
Capacity (kN) | Weight(kg) | |||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Plastic | Rubber | K | G | K | G | ||||||||
| 150 K | 80 | 90 | 150 | 30 | 50 | SF | SL | SD | 20 | 3,7 | |||
| 175 K | 80 | 90 | 175 | 30 | 50 | SF | SL | SD | 20 | 4,3 | |||
| 200 K | 80 | 90 | 200 | 30 | 50 | SF | SL | SD | 30 | 5,0 | |||
| 225 K | 80 | 90 | 225 | 30 | 50 | SF | SD | 30 | 5,8 | ||||
| 250 K | 80 | 90 | 250 | 30 | 50 | SF | SD | 35 | 6,7 | ||||
| 250 G | 130 | 145 | 250 | 30 | 50 | SF | SD | 10 | 9,0 | ||||
| 265 G | 160 | 175 | 265 | 30 | 50 | SF | SD | 15 | 10,0 | ||||
| 275 K | 80 | 90 | 275 | 30 | 50 | SF | SD | 35 | 7,6 | ||||
| 300 K | 80 | 90 | 300 | 30 | 50 | SF | SD | 35 | 8,7 | ||||
