MODEL S
MODEL S
MODEL S
Range of application
- For robust use eg on construction sites
- can be inserted as a machine part
- for transporting loads at a maximum speed of 100m/min
- When higher carrying capacity and greater sturdiness is required
- Impervious to shavings and dust
Characteristics
- Solid basic construction with ball bearings.
- Delivered with various castors
- Made in stainless-steel on request
- Special construction to suit customer requirements
- Passed the DIN 4422 test at the material research laboratory for steel whee´l 150 S
Hints on use
- Maintenance-free construction, used particularly in machine factories, on construction sites and for the handling of heavy goods.
- Can be combined with fixed castors and swivel castors (SF, SL, SD)
- Material with a high carrying capacity, wich is not very susceptible to rough handling.
- When a higher carrying capacity is required, they can be fitted with self-aligning roller bearings
- Can also be delivered as a flange wheel construction
- If there are problems with friction it can also be delivered with convex crowned wheel running surface (without additional charge)
- The chosen bearing dictates the maximum carrying capacity of the wheels.
| Size | a | b | Ø d1 | Ø d2 | Ø d3 | suitable suspensions of the series |
Capacity (kN) | Weight(kg) | ||
|---|---|---|---|---|---|---|---|---|---|---|
| Steel | ||||||||||
| 150S | 80 | 90 | 150 | 30 | 50 | SF | SL | SD | 30 | 9,7 |
| 175S | 80 | 90 | 175 | 30 | 50 | SF | SL | SD | 30 | 13,6 |
| 200S | 80 | 90 | 200 | 30 | 50 | SF | SL | SD | 30 | 18,1 |
| 225S | 80 | 90 | 225 | 30 | 50 | SF | SD | 30 | 23,3 | |
| 250S | 80 | 90 | 250 | 30 | 50 | SF | SD | 35 | 29,3 | |
| 275S | 80 | 90 | 275 | 30 | 50 | SF | SD | 35 | 36,3 | |
| 300S | 80 | 90 | 300 | 30 | 50 | SF | 35 | 44,4 | ||
