MODEL S-A(B), S-A(B)/P

Solid steel construction with ball bearings (S) or self-aligning roller bearings (S/P)
Delivered also as fixed castor
Special construction to suit customer requirements

Maintenance-free construction, used particularly in machine factories
Narrower distance between flange wheels if required, distances >55mm on request
Can be combined with fixed castors
Body of the wheel hardened optional with model …S (extra charge) and standard with model … S/P (without additional charge)

Mod.	a	b	c	Ø d1	Ø d2	Ø d3	Ø d4		suitable suspension of the series	Capacity (kN)	Weight (kg)
1 flange	2 flange											A	B
125 S-A	125 S-B	80	90	67,5	125	150	30	50	55	SF..S-A(B)	20	7,5	7,9
150 S-A	150 S-B	80	90	67,5	150	175	30	50	55	SF..S-A(B)	25	10,2	10,7
175 S-A	175 S-B	80	90	67,5	175	200	30	50	55	SF..S-A(B)	30	14,1	14,7
200 S-A	200 S-B	80	90	67,5	200	225	30	50	55	SF..S-A(B)	30	18,7	19,4

Mod.	a	b	c	Ø d1	Ø d2	Ø d3	Ø d4		suitable suspension of the series	Capacity (kN)
1 flange	2 flange											A	B
150 S-A/P	150 S-B/P	80	90	67,5	150	150	30	50	55	SF..S-A(B)/P	40	10,4	10,9
175 S-A/P	175 S-B/P	80	90	67,5	175	175	30	50	55	SF..S-A(B)/P	40	14,3	14,9
200 S-A/P	200 S-B/P	80	90	67,5	200	200	30	50	55	SF..S-A(B)/P	50	18,9	19,6
225 S-A/P	225 S-B/P	80	90	67,5	225	225	30	50	55	SF..S-A(B)/P	50	24,3	25,1
250 S-A/P	250 S-B/P	80	90	67,5	250	225	30	50	55	SF..S-A(B)/P	65	30,3	31,1
