MODEL S/P
MODEL S/P
MODEL S/P
Range of application
- For robust use e.g. on construction sites
- Can be inserted as a machine part
- for transporting loads at a maximum speed of 100 m/min
- When higher carrying capacity and greater sturdiness is required
- When higher safety standards and heavy duty are required
Characteristics
- Solid steel construction with self-aligning roller bearings
- Body hardened to 35-38 HRC with crowned wheel running surface
- Delivered with various mountings as fixed castors and swivel castors (SF, SL, SD)
Hints on use
- Maintenance-free construction, used particularly in machine factories, on construction sites and for the handling of heavy goods
- Can be combined with fixed castors and swivel castors
- Material with a high carrying capacity, wich is not very susceptible to rough handling
- Can also be delivered as a flange wheel construction (see model S-A/P; S-B/P)
| Mod. | a | b | Ø d1 | Ø d2 | Ø d3 | suitable suspension of the series |
Capacity (kN) | Weight (kg) | ||
|---|---|---|---|---|---|---|---|---|---|---|
| Steel | ||||||||||
| 150 S/P | 80 | 90 | 150 | 30 | 50 | SF | SL | SD | 50 | 9,9 |
| 175 S/P | 80 | 90 | 175 | 30 | 50 | SF | SL | SD | 50 | 13,8 |
| 200 S/P | 80 | 90 | 200 | 30 | 50 | SF | SL | SD | 60 | 18,3 |
| 225 S/P | 80 | 90 | 225 | 30 | 50 | SF | 60 | 23,5 | ||
| 250 S/P | 80 | 90 | 250 | 30 | 50 | SF | 80 | 29,5 | ||
| 275 S/P | 80 | 90 | 275 | 30 | 50 | SF | 80 | 36,5 | ||
| 300 S/P | 80 | 90 | 300 | 30 | 50 | SF | 80 | 44,6 |
