MODEL SD – S, K, S/P

MODEL SD – S, K, S/P

Range of application

For transporting loads at a maximum speed of 100m/min.
For turning corners
Frequently used on construction sites

Characteristics

Solid steel construction of the rotating mountings.
Can be combined with other castors.

Model SD-S, SD-K

Size		a	b	c	∅d1	∅e	f	g	h	j	k	Fitting to model		Capacity(KN)		Weight (kg)
Steel	Plastic													S	K	S	K
SF 150 S	SF 150 K	220	150	190	150	14	115	15	210	80	120	SF		30	20	21,4	15,4
SF 175 S	SF 175 K	220	150	190	175	14	115	15	235	80	120	SF		30	20	26,2	16,9
SF 200 S	SF 200 K	220	150	190	200	14	115	15	260	80	120	SF		30	30	31,6	18,5
SF 225 S	SF 225 K	270	210	210	225	18	150	15	285	80	120	SF		30	30	40,4	22,9
SF 250 S	SF 250 K	270	210	210	250	18	150	15	310	80	120	SF		35	35	47,3	24,7
SF 275 S	SF 275 K	270	210	210	275	18	150	15	335	80	120	SF		35	35	55,2	26,5

Model SD-S/P

Size		a	b	c	∅d1	∅e	f	g	h	j	k	Fitting to model		Capacity(KN)		Weight (kg)
Steel														S
SF 150 S		270	170	220	150	18	130	20	220	80	130	SF		50		21,6
SF 175 S		270	170	220	175	18	130	20	245	80	130	SF		50		26,4
SF 200 S		270	170	220	200	18	130	20	285	80	130	SF		50		31,8
